　↓ Products List：—— CSB Series


Bearing No.
Shaft Dia
Boundary dimensions(mm)
Basic load ratings
Mass(Kg)
in.
mm
D
Bi
Be
n
m
G
ds
C
Co
≈
CSB201
　
12
40
22
12
6
16
4
M6x1.0
2160
990
0.1
CSB201-8
1/2
　
40
22
12
6
16
4
1/4-28UNF
2160
990
0.1
CSB202
　
15
40
22
12
6
16
4
M6x1.0
2160
990
0.09
CSB202-10
5/8
　
40
22
12
6
16
4
1/4-28UNF
2160
990
0.09
CSB203
　
17
40
22
12
6
16
4
M6x1.0
2160
990
0.08
CSB204
　
20
47
25
14
7
18
5
M6x1.0
12890
6490
0.13
CSB204-12
3/4
　
47
25
14
7
18
5
1/4-28UNF
12890
6490
0.13
CSB205
　
25
52
27
15
7.5
19.5
5.5
M6x1.0
14000
7560
0.16
CSB205-14
7/8
　
52
27
15
7.5
19.5
5.5
1/4-28UNF
14000
7560
0.18
CSB205-15
15/16
　
52
27
15
7.5
19.5
5.5
1/4-28UNF
14000
7560
0.18
CSB205-16
1
　
52
27
15
7.5
19.5
5.5
1/4-28UNF
14000
7560
0.16
CSB206
　
30
62
30
16
8
22
6
M8x1.0
19510
11160
0.25
CSB206-17
1-1/16
　
62
30
16
8
22
6
5/16-24UNF
19510
11160
0.27
CSB206-18
1-1/8
　
62
30
16
8
22
6
5/16-24UNF
19510
11160
0.26
CSB206-19
1-3/16
　
62
30
16
8
22
6
5/16-24UNF
19510
11160
0.25
CSB206-20
1-1/4
　
62
30
16
8
22
6
5/16-24UNF
19510
11160
0.24
CSB207
　
35
72
32
17
8.5
23.5
6
M8x1.0
25650
15340
0.38
CSB207-20
1-1/4
　
72
32
17
8.5
23.5
6
5/16-24UNF
25650
15340
0.43
CSB207-21
1-5/16
　
72
32
17
8.5
23.5
6
5/16-24UNF
25650
15340
0.42
CSB207-22
1-3/8
　
72
32
17
8.5
23.5
6
5/16-24UNF
25650
15340
0.38
CSB207-23
1-7/16
　
72
32
17
8.5
23.5
6
5/16-24UNF
25650
15340
0.31
CSB208
　
40
80
34
18
9
25
8
M8x1.0
28890
17110
0.5
CSB208-24
1-1/2
　
80
34
18
9
25
8
5/16-24UNF
28890
17110
0.52
