| ↓ Products List：—— H3000 Series |
|
 |
 |
|
Adapter |
Shaft d1 |
Dimensions(mm) |
Weight |
Composition |
|
Sleeve |
H |
HE |
HA |
d |
d2 |
B1 |
B2 |
G |
Kg |
Sleeve |
Locknut |
Lockwasher |
Lockcard |
|
|
mm |
in |
in |
≈ |
|
H3120 |
90 |
3-1/2 |
3-7/16 |
100 |
130 |
76 |
20 |
M100×2 |
1.8 |
A3120 |
KM20 |
MB20 |
|
|
H3122 |
100 |
4 |
3-15/16 |
110 |
145 |
81 |
21 |
M110×2 |
2.4 |
A3122 |
KM22 |
MB22 |
|
|
H3124 |
110 |
4-1/4 |
4-3/16 |
120 |
155 |
88 |
22 |
M120×2 |
2.65 |
A3124 |
KM24 |
MB24 |
|
|
H3126 |
115 |
4-1/2 |
4-7/16 |
130 |
165 |
92 |
23 |
M130×2 |
3.65 |
A3126 |
KM26 |
MB26 |
|
|
H3128 |
125 |
5 |
4-15/16 |
140 |
180 |
97 |
24 |
M140×2 |
4.35 |
A3128 |
KM28 |
MB28 |
|
|
H3130 |
135 |
5-1/4 |
5-3/16 |
150 |
195 |
111 |
26 |
M150×2 |
5.5 |
A3130 |
KM30 |
MB30 |
|
|
H3132 |
140 |
5-1/2 |
5-7/16 |
160 |
210 |
119 |
28 |
M160×3 |
7.65 |
A3132 |
KM32 |
MB32 |
|
|
H3134 |
150 |
6 |
5-15/16 |
170 |
220 |
122 |
29 |
M170×3 |
8.4 |
A3134 |
KM34 |
MB34 |
|
|
H3136 |
160 |
6-1/2 |
6-7/16 |
180 |
230 |
131 |
30 |
M180×3 |
9.5 |
A3136 |
KM36 |
MB36 |
|
|
H3138 |
170 |
6-3/4 |
6-15/16 |
190 |
240 |
141 |
31 |
M190×3 |
11 |
A3138 |
KM38 |
MB38 |
|
|
H3140 |
180 |
7 |
7-3/16 |
200 |
250 |
150 |
32 |
M200×3 |
12 |
A3140 |
KM40 |
MB40 |
|
|
H3144 |
200 |
|
7-15/16 |
220 |
280 |
161 |
44 |
T220×4 |
15 |
A3144 |
KM44 |
|
MS44 |
|
H3148 |
220 |
|
|
240 |
300 |
172 |
46 |
T240×4 |
18 |
A3148 |
KM48 |
|
MS48 |
|
H3152 |
240 |
|
|
260 |
330 |
190 |
49 |
T260×4 |
22.5 |
A3152 |
KM52 |
|
MS52 |
|
H3156 |
260 |
|
|
280 |
350 |
195 |
51 |
T280×4 |
25 |
A3156 |
KM56 |
|
MS56 |
|
H3160 |
280 |
|
|
300 |
380 |
208 |
53 |
T300×4 |
30 |
A3160 |
KM60 |
|
MS60 |
|
H3164 |
300 |
|
|
320 |
400 |
226 |
56 |
T320×5 |
35 |
A3164 |
KM64 |
|
MS64 |
|
H3168 |
320 |
|
|
340 |
440 |
254 |
72 |
T340×5 |
|
A3168 |
KM68 |
|
MS68 |
|
H3172 |
340 |
|
|
360 |
460 |
259 |
75 |
T360×5 |
|
A3172 |
KM72 |
|
MS72 |
|
H3176 |
360 |
|
|
380 |
490 |
264 |
77 |
T380×5 |
|
A3176 |
KM76 |
|
MS76 |
|
H3180 |
380 |
|
|
400 |
520 |
272 |
82 |
T400×5 |
|
A3180 |
KM80 |
|
MS80 |
|
H3184 |
400 |
|
|
420 |
540 |
304 |
90 |
T420×5 |
|
A3184 |
KM84 |
|
MS84 |
|
H3188 |
410 |
|
|
440 |
560 |
307 |
90 |
T440×5 |
|
A3188 |
KM88 |
|
MS88 |
|
H3192 |
430 |
|
|
460 |
580 |
326 |
95 |
T460×5 |
|
A3192 |
KM92 |
|
MS92 |
|
H3196 |
450 |
|
|
480 |
620 |
335 |
95 |
T480×5 |
|
A3196 |
KM96 |
|
MS96 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
H3024 |
110 |
4-1/4 |
4-3/16 |
120 |
145 |
72 |
22 |
M120×2 |
1.95 |
A3024 |
KML24 |
MBL24 |
|
|
H3026 |
115 |
4-1/2 |
4-7/16 |
130 |
155 |
80 |
23 |
M130×2 |
2.85 |
A3026 |
KML26 |
MBL26 |
|
|
H3028 |
125 |
5 |
4-15/16 |
140 |
165 |
82 |
24 |
M140×2 |
3.15 |
A3028 |
KML28 |
MBL28 |
|
|
H3030 |
135 |
5-1/4 |
5-3/16 |
150 |
180 |
87 |
26 |
M150×2 |
3.9 |
A3030 |
KML30 |
MBL30 |
|
|
H3032 |
140 |
5-1/2 |
5-7/16 |
160 |
190 |
93 |
28 |
M160×3 |
5.2 |
A3032 |
KML32 |
MBL32 |
|
|
H3034 |
150 |
6 |
5-15/16 |
170 |
200 |
101 |
29 |
M170×3 |
6 |
A3034 |
KML34 |
MBL34 |
|
|
H3036 |
160 |
6-1/2 |
6-7/16 |
180 |
210 |
109 |
30 |
M180×3 |
6.85 |
A3036 |
KML36 |
MBL36 |
|
|
H3038 |
170 |
6-3/4 |
6-15/16 |
190 |
220 |
112 |
31 |
M190×3 |
7.45 |
A3038 |
KML38 |
MBL38 |
|
|
H3040 |
180 |
7 |
7-3/16 |
200 |
240 |
120 |
32 |
M200×3 |
9.2 |
A3040 |
KML40 |
MBL40 |
|
|
H3044 |
200 |
|
7-15/16 |
220 |
260 |
126 |
41 |
T220×4 |
10.5 |
A3044 |
KML44 |
|
MSL44 |
|
H3048 |
220 |
|
8-15/16 |
240 |
290 |
133 |
46 |
T240×4 |
13 |
A3048 |
KML48 |
|
MSL48 |
|
H3052 |
240 |
|
9-7/16 |
260 |
310 |
145 |
46 |
T260×4 |
15.5 |
A3052 |
KML52 |
|
MSL52 |
|
H3056 |
260 |
|
10-7/16 |
280 |
330 |
152 |
50 |
T280×4 |
17.5 |
A3056 |
KML56 |
|
MSL56 |
|
H3060 |
280 |
|
10-15/16 |
300 |
360 |
168 |
54 |
T300×4 |
23 |
A3060 |
KML60 |
|
MSL60 |
|
H3064 |
300 |
|
11-15/16 |
320 |
380 |
171 |
55 |
T320×5 |
24.5 |
A3064 |
KML64 |
|
MSL64 |
|
H3068 |
320 |
|
12-7/16 |
340 |
400 |
187 |
58 |
T340×5 |
28.5 |
A3068 |
KML68 |
|
MSL68 |
|
H3072 |
340 |
|
13-7/16 |
360 |
420 |
188 |
58 |
T360×5 |
30.5 |
A3072 |
KML72 |
|
MSL72 |
|
H3076 |
360 |
|
13-15/16 |
380 |
450 |
193 |
62 |
T380×5 |
36 |
A3076 |
KML76 |
|
MSL76 |
|
H3080 |
380 |
|
|
400 |
470 |
210 |
66 |
T400×5 |
41.5 |
A3080 |
KML80 |
|
MSL80 |
|
H3084 |
400 |
|
|
420 |
490 |
212 |
66 |
T420×5 |
43.5 |
A3084 |
KML84 |
|
MSL84 |
|
H3088 |
410 |
|
|
440 |
520 |
228 |
77 |
T440×5 |
65.2 |
A3088 |
KML88 |
|
MSL88 |
|
H3092 |
430 |
|
|
460 |
540 |
234 |
77 |
T460×5 |
69.5 |
A3092 |
KML92 |
|
MSL92 |
|
H3096 |
450 |
|
|
480 |
560 |
237 |
77 |
T480×5 |
73.5 |
A3096 |
KML96 |
|
MSL96 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Adapter Sleeve |
Dimensions(mm) |
Weight (Kg) |
Composition |
|
|
|
|
d1 |
d |
d2 |
B1 |
B2 |
G |
Sleeve |
Locknut |
Lockcard |
|
|
|
|
H3260 |
280 |
300 |
380 |
240 |
53 |
T300x4 |
34.1 |
A3260 |
KM60 |
MS60 |
|
|
|
|
H3264 |
300 |
320 |
400 |
258 |
56 |
T320x5 |
39.3 |
A3264 |
KM64 |
MS64 |
|
|
|
|
H3268 |
320 |
340 |
440 |
288 |
72 |
T340x5 |
54.6 |
A3268 |
KM68 |
MS68 |
|
|
|
|
H3272 |
340 |
360 |
460 |
299 |
75 |
T360x5 |
60.2 |
A3272 |
KM72 |
MS72 |
|
|
|
|
H3276 |
360 |
380 |
490 |
310 |
77 |
T380x5 |
69.6 |
A3276 |
KM76 |
MS76 |
|
|
|
|
H3280 |
380 |
400 |
520 |
328 |
82 |
T400x5 |
81 |
A3280 |
KM80 |
MS80 |
|
|
|
|
H3284 |
400 |
420 |
540 |
352 |
90 |
T420x5 |
94 |
A3284 |
KM84 |
MS84 |
|
|
|
|
H3288 |
410 |
440 |
560 |
361 |
90 |
T440x5 |
118 |
A3288 |
KM88 |
MS88 |
|
|
|
|
H3292 |
430 |
460 |
580 |
382 |
95 |
T460x5 |
132 |
A3292 |
KM92 |
MS92 |
|
|
|
|
H3296 |
450 |
480 |
620 |
397 |
95 |
T480x5 |
152 |
A3296 |
KM96 |
MS96 |
|
|
| |
|
|
|
|
