| ↓ Products List：—— H2300 Series |
|
 |
 |
|
Adapter |
Shaft d1 |
Dimensions(mm) |
Weight |
Composition |
|
Sleeve |
H |
HE |
HS |
HA |
d |
d2 |
B1 |
B2 |
G |
Kg |
Sleeve |
Locknut |
Lockwasher |
Lockcard |
|
No. |
mm |
in |
in |
in |
≈ |
|
H2304 |
17 |
|
|
|
20 |
32 |
31 |
7 |
M20×1 |
0.049 |
A2304 |
KM04 |
MB04 |
|
|
H2305 |
20 |
3/4 |
7/8 |
13/16 |
25 |
38 |
35 |
8 |
M25×1.5 |
0.087 |
A2305 |
KM05 |
MB05 |
|
|
H2306 |
25 |
1 |
7/8 |
15/16 |
30 |
45 |
38 |
8 |
M30×1.5 |
0.126 |
A2306 |
KM06 |
MB06 |
|
|
H2307 |
30 |
1-1/4 |
1-1/8 |
1-3/16 |
35 |
52 |
43 |
9 |
M35×1.5 |
0.17 |
A2307 |
KM07 |
MB07 |
|
|
H2308 |
35 |
1-1/4 |
1-3/8 |
1-5/16 |
40 |
58 |
46 |
10 |
M40×1.5 |
0.224 |
A2308 |
KM08 |
MB08 |
|
|
H2309 |
40 |
1-1/2 |
1-5/8 |
1-7/16 |
45 |
65 |
50 |
11 |
M45×1.5 |
0.28 |
A2309 |
KM09 |
MB09 |
|
|
H2310 |
45 |
1-3/4 |
1-5/8 |
1-11/16 |
50 |
70 |
55 |
12 |
M50×1.5 |
0.362 |
A2310 |
KM10 |
MB10 |
|
|
H2311 |
50 |
2 |
1-7/8 |
1-15/16 |
55 |
75 |
59 |
12 |
M55×2 |
0.42 |
A2311 |
KM11 |
MB11 |
|
|
H2312 |
55 |
2-1/4 |
2-1/8 |
2-1/16 |
60 |
80 |
62 |
13 |
M60×2 |
481 |
A2312 |
KM12 |
MB12 |
|
|
H2313 |
60 |
2-1/4 |
2-3/8 |
2-3/16 |
65 |
85 |
65 |
14 |
M65×2 |
0.557 |
A2313 |
KM13 |
MB13 |
|
|
H2314 |
60 |
|
|
|
70 |
92 |
68 |
14 |
M70×2 |
0.9 |
A2314 |
KM14 |
MB14 |
|
|
H2315 |
65 |
2-1/2 |
2-5/8 |
2-7/16 |
75 |
98 |
73 |
15 |
M75×2 |
1.05 |
A2315 |
KM15 |
MB15 |
|
|
H2316 |
70 |
2-3/4 |
2-7/8 |
2-11/16 |
80 |
105 |
78 |
17 |
M80×2 |
1.28 |
A2316 |
KM16 |
MB16 |
|
|
H2317 |
75 |
3 |
|
2-15/16 |
85 |
110 |
82 |
18 |
M85×2 |
1.45 |
A2317 |
KM17 |
MB17 |
|
|
H2318 |
80 |
3-1/4 |
3-1/8 |
3-3/16 |
90 |
120 |
86 |
18 |
M90×2 |
1.69 |
A2318 |
KM18 |
MB18 |
|
|
H2319 |
85 |
3-1/4 |
|
3-5/16 |
95 |
125 |
90 |
19 |
M95×2 |
1.92 |
A2319 |
KM19 |
MB19 |
|
|
H2320 |
90 |
3-1/2 |
|
3-7/16 |
100 |
130 |
97 |
20 |
M100×2 |
2.15 |
A2320 |
KM20 |
MB20 |
|
|
H2321 |
95 |
|
|
|
105 |
140 |
101 |
20 |
M105×2 |
2.46 |
A2321 |
KM21 |
MB21 |
|
|
H2322 |
100 |
4 |
|
3-15/16 |
110 |
145 |
105 |
21 |
M110×2 |
2.75 |
A2322 |
KM22 |
MB22 |
|
|
H2324 |
110 |
4-1/4 |
|
4-3/16 |
120 |
155 |
112 |
22 |
M120×2 |
3.2 |
A2324 |
KM24 |
MB24 |
|
|
H2326 |
115 |
4-1/2 |
|
4-7/16 |
130 |
165 |
121 |
23 |
M130×2 |
4.6 |
A2326 |
KM26 |
MB26 |
|
|
H2328 |
125 |
5 |
4-13/16 |
4-15/16 |
140 |
180 |
131 |
24 |
M140×2 |
5.55 |
A2328 |
KM28 |
MB28 |
|
|
H2330 |
135 |
5-1/4 |
|
5-3/16 |
150 |
195 |
139 |
26 |
M150×2 |
6.63 |
A2330 |
KM30 |
MB30 |
|
|
H2332 |
140 |
5-1/2 |
|
5-7/16 |
160 |
210 |
147 |
28 |
M160×3 |
9.15 |
A2332 |
KM32 |
MB32 |
|
|
H2334 |
150 |
6 |
|
5-15/16 |
170 |
220 |
154 |
29 |
M170×3 |
10.2 |
A2334 |
KM34 |
MB34 |
|
|
H2336 |
160 |
6-1/2 |
|
6-7/16 |
180 |
230 |
161 |
30 |
M180×3 |
11.3 |
A2336 |
KM36 |
MB36 |
|
|
H2338 |
170 |
6-3/4 |
|
6-15/16 |
190 |
240 |
169 |
31 |
M190×3 |
12.6 |
A2338 |
KM38 |
MB38 |
|
|
H2340 |
180 |
7 |
|
7-3/16 |
200 |
250 |
176 |
32 |
M200×3 |
14 |
A2340 |
KM40 |
MB40 |
|
|
H2344 |
200 |
|
|
|
220 |
280 |
186 |
44 |
T220×4 |
16.7 |
A2344 |
HM44 |
|
MS44 |
|
H2348 |
220 |
|
|
|
240 |
300 |
199 |
46 |
T240×4 |
29.7 |
A2348 |
HM48 |
|
MS48 |
|
H2352 |
240 |
|
|
|
260 |
330 |
211 |
49 |
T260×4 |
24.2 |
A2352 |
HM52 |
|
MS52 |
|
H2356 |
260 |
|
|
|
280 |
350 |
224 |
51 |
T280×4 |
27.8 |
A2356 |
HM56 |
|
MS56 | |
|
|
|
|
