Unit No.	Dimensions (mm)							Inner flange		Outer flange bolt	No. of	Unit	Outer flange
	A	B	C	D	E	F	G	Bolt hole size (Q'ty)	Bolt size (Q'ty)	hole size & hole Dia.	Splines	Model	shape
								H		I	J	K	S
100104	116.8	98	58.9	57.9	-	52	85	4xM12x1.25	-	4 x Ø10 x .25	20	X	II
513017K	125.4	100	58.32	57.02	73.4	44.3	98.5	-	5 x M12 x 1.5	3 x Ø12.7	33	X	I
513016K	146	115	70.63	70.15	89.95	41.78	116	-	5 x M12 x 1.5	3 x Ø12.7	27	X	I
513084	154	114.3	72	71.4	100	54	120.65	-	5 x 1/2-20UNF	3 x M12 x 1.75	27	X	I
52730-38102	148	114.3	75.9	66.9	65.9	59	100	-	4 x M12 x 1.5	4 x M10 x 1.25	-	Y	V
513074	139	114.3	72.8	71.2	86.8	37.7	112	-	5 x M12 x 1.5	4 x M10 x 1.5	26	X	II
513075	126	100	60.7	56.7	87	37.3	112	-	5 x M12 x 1.5	4 x M10 x 1.5	26	X	II
513011K	125.4	100	57.73	57.03	70.99	41.96	102	-	5 x M12 x 1.5	3 x Ø13	33	X	I
574566B	135.5	108	68	65	83.5	43	103	4 x M12 x 1.75	-	4 x M12 x 1.75	26	Z	III
574566C	135.5	108	68	65	83.5	43	103	5 x M12 x 1.75	-	4 x M12 x 1.75	26	Z	III
BARB243823AD	130.5	108	68	65	81	37	103	4 x M14 x 1.5	-	4 x M12 x 1.5	26	Z	V
633293	116.8	98	58.9	57.9	-	52	85	4 x M12 x 1.25	-	4 x Ø10 x 1.25	-	X	II
801143D	-	-	-	-	-	-	-	-	-	-	-	Y	V
513100	139	108	70.92	63.1	85.44	36.2	112	-	5 x M12 x 1.5	3 x M12 x 1.75	26	X	I
513087	145.5	115	70.61	70.1	-	42	116	-	5 x M12 x 1.5	3 x Ø14	33	X	I
513138	128	100	60.9	56.9	87	37.6	112	-	5 x M12 x 1.5	3 x M12 x 1.75	26	X	I
513121	145.8	115	70.6	70.1	-	41.9	116	-	5 x M12 x 1.5	3 x M12 x 1.75	33	X	I
513044	144.5	115	70.61	70.1	91.06	44.85	146.05	-	5 x M12 x 1.5	4 x M12 x1.5	33	X	V
513089	146	114.3	73.3	71.4	91.3	42.1	116	-	5 x M12 x 1.5	3 x M12 x 1.75	33	X	I
513061	144.5	120.65	70.63	71.14	91.95	47.24	120.65	-	5 x M12 x 1.5	3 x M12 x 1.75	27	Z	I
30BWK16	151.8	114.3	62	60	-	75	99	5 x M12 x 1.5	-	4 x Ø10.5	-	Y	V
3NDF026	135	100	54.95	53.92	73.9	54.5	-	-	4 x M12 x 1.5	4 x M10 x 1.25	-	Z	V
801106	139	120	79	74	90	61.1	106	5 x M12 x 1.5	-	4 x M12 x 1.5	-	Y	VI
801344D	131	112	68	57	-	70.15	95	5 x M14 x 1.5	-	5 x Ø10.8	-	Z	V
512001ABS	138	-	56.8	57.3	60.9	65	-	-	5 x M12 x 1.5	4 x Ø10.8	-	X	VII
513156	139	-	63.1	70.8	89.5	41.1	-	-	5 x M12 x 1.5	3 x M12 x 1.75	26	X	I
515001ABS	182.5	140	77.6	78.3	99.3	56.7	-	-	6 x M14 x 1.5	3 x Ø14.5	33	X	I
515006	172	-	77.6	78	99.3	-	50.8	-	5 x 1/2-20UNF	3 x M14 x 1.5	33	X	I
