Seal Type |
Ball |
Open Type |
Ball |
Adjustable type |
Ball |
dr |
D |
L |
B |
W |
D1 |
h |
h1 |
Ө |
|
Circuit |
Circuit |
Circuit |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
|
LM4UU |
4 |
|
|
LM4UUAJ |
4 |
4 |
8 |
12 |
|
|
|
1 |
|
|
|
LM5UU |
4 |
|
|
LM5UUAJ |
4 |
5 |
10 |
15 |
10.2 |
1.1 |
9.6 |
1 |
|
|
|
LM6UU |
4 |
|
|
LM6UUAJ |
4 |
6 |
12 |
19 |
13.5 |
1.1 |
11.5 |
1 |
|
|
|
LM8SUU |
4 |
|
|
LM8SUUAJ |
4 |
8 |
15 |
17 |
11.5 |
1.1 |
14.3 |
1 |
|
|
|
LM8UU |
4 |
|
|
LM8UUAJ |
4 |
8 |
16 |
24 |
17.5 |
1.1 |
14.3 |
1 |
|
|
|
LM10UU |
4 |
|
|
LM10UUAJ |
4 |
10 |
19 |
29 |
22 |
1.3 |
18 |
1 |
6.8 |
80o |
|
LM12UU |
4 |
|
|
LM12UUAJ |
4 |
12 |
21 |
30 |
23 |
1.3 |
20 |
1.5 |
8 |
80o |
|
LM13UU |
4 |
|
|
LM13UUAJ |
4 |
13 |
23 |
32 |
23 |
1.3 |
22 |
1.5 |
9 |
80o |
|
LM16UU |
5 |
LM16UUOP |
4 |
LM16UUAJ |
5 |
16 |
28 |
37 |
26.5 |
1.6 |
27 |
1.5 |
11 |
60o |
|
LM20UU |
6 |
LM20UUOP |
4 |
LM20UUAJ |
5 |
20 |
32 |
42 |
30.5 |
1.6 |
30.5 |
1.5 |
11 |
50o |
|
LM25UU |
6 |
LM25UUOP |
5 |
LM25UUAJ |
6 |
25 |
40 |
59 |
41 |
1.85 |
38 |
2 |
12.5 |
50o |
|
LM30UU |
6 |
LM30UUOP |
5 |
LM30UUAJ |
6 |
30 |
45 |
64 |
44.5 |
1.85 |
43 |
2.5 |
15 |
50o |
|
LM35UU |
6 |
LM35UUOP |
5 |
LM35UUAJ |
6 |
35 |
52 |
70 |
49.5 |
2.1 |
49 |
2.5 |
17 |
50o |
|
LM40UU |
6 |
LM40UUOP |
5 |
LM40UUAJ |
6 |
40 |
60 |
80 |
60.5 |
2.1 |
57 |
3 |
20 |
50o |
|
LM50UU |
6 |
LM50UUOP |
5 |
LM50UUAJ |
6 |
50 |
80 |
100 |
74 |
2.6 |
76.5 |
3 |
25 |
50o |
|
LM60UU |
6 |
LM60UUOP |
5 |
LM60UUAJ |
6 |
60 |
90 |
110 |
81 |
3.15 |
86.5 |
3 |
30 |
50o |
Other available types: LMF/LMEF, LMH, LMK/LMEK, SC-L, SH, SHL, SC, SMH,PL, SMY, SHA, SMEL, SHF, SME Series |
