| ↓ Products List：—— SI..ET-2RS Series |
|
 |
 |
|
Bearing No. |
Boundary dimensions(mm) |
Mass |
|
d |
B |
dk |
C1 |
d2 |
G |
h1 |
l3 |
l4 |
l5 |
W |
d3 |
d4 |
rs |
α° |
Kg |
|
max |
max |
6H |
min |
max |
max |
max |
max |
min |
≈ |
≈ |
|
SI35ET-2RS |
35 |
25 |
47 |
22 |
82 |
M36×3 |
125 |
60 |
166 |
15 |
55 |
48 |
58 |
0.6 |
6 |
1.5 |
|
SI40ET-2RS |
40 |
28 |
53 |
24 |
92 |
M39×3 |
142 |
65 |
188 |
18 |
60 |
52 |
65 |
0.6 |
7 |
2.1 |
|
SI45ET-2RS |
45 |
32 |
60 |
28 |
102 |
M42×3 |
145 |
65 |
196 |
20 |
65 |
58 |
70 |
0.6 |
7 |
2.7 |
|
SI50ET-2RS |
50 |
35 |
66 |
31 |
112 |
M45×3 |
160 |
68 |
216 |
20 |
70 |
62 |
75 |
0.6 |
6 |
3.5 |
|
SI60ET-2RS |
60 |
44 |
80 |
39 |
135 |
M52×3 |
175 |
70 |
242.5 |
20 |
80 |
70 |
88 |
1 |
6 |
5.6 |
|
SI70ET-2RS |
70 |
49 |
92 |
43 |
160 |
M56×4 |
200 |
80 |
280 |
20 |
85 |
80 |
98 |
1 |
6 |
8.3 |
|
SI80ET-2RS |
80 |
55 |
105 |
48 |
180 |
M64×4 |
230 |
85 |
320 |
25 |
95 |
95 |
110 |
1 |
6 |
13 | |
|
|
|
|
