| ↓ Products List：—— SAZJ...Series |
|
 |
 |
|
Bearing No. |
Boundary dimensions(mm) |
Mass |
|
d |
B |
dk |
C1 |
d2 |
G |
h |
l1 |
l2 |
rs |
α° |
Kg |
|
max |
max |
(inch) |
min |
max |
min |
≈ |
≈ |
|
SAZJ4 |
4.83 |
7.92 |
11.1 |
5.94 |
15.88 |
10-32 |
31.75 |
19.05 |
39.7 |
0.3 |
10 |
0.014 |
|
SAZJ6 |
6.35 |
9.53 |
12.7 |
6.35 |
19.05 |
1/4-28 |
39.67 |
25.4 |
49.2 |
0.3 |
13.5 |
0.018 |
|
SAZJ7 |
7.94 |
11.1 |
15.88 |
7.92 |
22.23 |
5/16-24 |
47.63 |
31.75 |
58.72 |
0.3 |
11 |
0.032 |
|
SAZJ9 |
9.53 |
12.7 |
18.26 |
9.12 |
25.4 |
3/8-24 |
49.23 |
31.75 |
61.93 |
0.6 |
11 |
0.05 |
|
SAZJ11 |
11.11 |
14.27 |
20.62 |
10.31 |
28.58 |
7/16-20 |
53.98 |
34.93 |
68.28 |
0.6 |
10.5 |
0.068 |
|
SAZJ12 |
12.7 |
15.88 |
23.81 |
11.05 |
33.32 |
1/2-20 |
61.93 |
38.1 |
78.59 |
0.6 |
10 |
0.11 |
|
SAZJ15 |
15.88 |
19.05 |
28.58 |
12.29 |
38.1 |
5/8-18 |
66.68 |
41.28 |
85.73 |
0.6 |
13 |
0.16 |
|
SAZJ19 |
19.05 |
22.23 |
33.32 |
15.06 |
44.45 |
3/4-16 |
73.03 |
44.45 |
95.25 |
0.6 |
12 |
0.26 | |
|
|
|
|
