| ↓ Products List：—— SIZP...S Series |
|
 |
 |
|
Bearing No. |
Boundary dimensions(mm) |
Mass |
|
d |
B |
dk |
C1 |
d2 |
G |
h1 |
l3 |
l4 |
l5 |
W |
d3 |
d4 |
rs |
α° |
Kg |
|
max |
max |
(inch) |
min |
max |
max |
max |
max |
min |
≈ |
≈ |
|
SIZP4S |
4.83 |
7.92 |
11.1 |
6.35 |
15.88 |
10-32 |
26.97 |
14.27 |
34.93 |
4.75 |
7.92 |
7.54 |
10.31 |
0.3 |
10 |
0.015 |
|
SIZP6S |
6.35 |
9.53 |
12.7 |
7.14 |
19.05 |
1/4-28 |
33.32 |
19.05 |
42.85 |
4.75 |
9.53 |
9.15 |
11.91 |
0.3 |
13 |
0.025 |
|
SIZP7S |
7.94 |
11.1 |
15.88 |
8.74 |
22.23 |
5/16-24 |
34.93 |
19.05 |
46.02 |
4.75 |
11.1 |
10.72 |
12.7 |
0.3 |
10 |
0.036 |
|
SIZP9S |
9.53 |
12.7 |
18.26 |
10.31 |
25.4 |
3/8-24 |
41.28 |
23.8 |
53.98 |
6.35 |
14.27 |
13.89 |
17.45 |
0.6 |
9 |
0.061 |
|
SIZP11S |
11.11 |
14.27 |
20.62 |
11.1 |
28.58 |
7/16-20 |
46.02 |
26.97 |
60.33 |
6.35 |
15.88 |
15.49 |
19.05 |
0.6 |
11 |
0.081 |
|
SIZP12S |
12.7 |
15.88 |
23.81 |
12.7 |
33.32 |
1/2-20 |
53.98 |
30.15 |
70.64 |
6.35 |
19.05 |
18.67 |
22.23 |
0.6 |
9 |
0.133 |
|
SIZP15S |
15.88 |
19.05 |
28.58 |
14.27 |
38.1 |
5/8-18 |
63.5 |
38.1 |
82.55 |
7.92 |
22.23 |
21.84 |
25.4 |
0.6 |
11 |
0.19 |
|
SIZP19S |
19.05 |
22.23 |
33.32 |
17.45 |
44.45 |
3/4-16 |
73.03 |
44.45 |
95.25 |
7.92 |
25.4 |
25.02 |
28.58 |
0.6 |
10 |
0.285 |
|
SIZP25S |
25.4 |
34.93 |
47.63 |
25.4 |
69.85 |
5/4-12 |
104.78 |
53.98 |
139.7 |
11.1 |
38.1 |
37.72 |
44.45 |
0.6 |
14 |
1 | |
|
|
|
|
