| ↓ Products List：—— SI ...E Series |
|
 |
 |
|
Bearing No. |
Boundary dimensions(mm) |
Mass |
|
d |
B |
dk |
C1 |
d2 |
G |
h1 |
l3 |
l4 |
l5 |
W |
d3 |
d4 |
rs |
α° |
Kg |
|
max |
max |
6H |
min |
max |
max |
max |
max |
min |
≈ |
≈ |
|
SI5E |
5 |
6 |
10 |
4.5 |
21 |
M5 |
30 |
11 |
40.5 |
5 |
10 |
10 |
13 |
0.3 |
13 |
0.016 |
|
SI6E |
6 |
6 |
10 |
4.5 |
21 |
M6 |
30 |
11 |
40.5 |
5 |
11 |
11 |
13 |
0.3 |
13 |
0.017 |
|
SI8E |
8 |
8 |
13 |
6.5 |
24 |
M8 |
36 |
15 |
48 |
5 |
13 |
13 |
16 |
0.3 |
15 |
0.035 |
|
SI10E |
10 |
9 |
16 |
7.5 |
29 |
M10 |
43 |
15 |
57.5 |
6.5 |
16 |
16 |
19 |
0.3 |
12 |
0.061 |
|
SI12E |
12 |
10 |
18 |
8.5 |
34 |
M12 |
50 |
18 |
67 |
7 |
18 |
19 |
22 |
0.3 |
10 |
0.096 | |
|
|
|
|
