　↓ Products List：—— PHS Series


Bearing No.
 Boundary dimensions                mm
Load ratings   kN
Mass
d
B
dK
C1
d2
G
h1
l3
l4
l5
l7
W
d3
d4
rs
αⅹ
Dynamic
Static
Kg
max
6H
min
min
≈
≈
PHS 5
5
8
11.112
6
16
M5
27
14
35
4
8
9
9
11
0.3
13
3.3
4.1
0.016
PHS 6
6
9
12.7
6.75
18
M6
30
14
39
5
9
11
10
13
0.3
13
4.3
5.3
0.026
PHS 8
8
12
15.88
9
22
M8
36
17
47
5
11
14
12.5
16
0.3
14
6.8
8.5
0.044
PHS 10
10
14
19.05
10.5
26
M10
43
21
56
6.5
13
17
15
19
0.3
14
10
11
0.072
PHS 12
12
16
22.23
12
30
M12
50
24
65
6.5
15
19
17.5
22
0.3
13
13
14
0.108
PHS 14
14
19
25.4
13.5
34
M14
57
27
74
8
16
22
20
25
0.3
16
17
20
0.161
PHS 16
16
21
28.58
15
38
M16
64
33
83
8
17.5
22
22
27
0.3
15
21
25
0.225
PHS 18
18
23
31.75
16.5
42
M18×1.5
71
36
92
10
19.5
27
25
31
0.6
15
26
30
0.295
PHS 20
20
25
34.93
18
46
M20×1.5
77
40
100
10
21.5
30
27.5
34
0.6
15
31
35
0.382
PHS 22
22
28
38.1
20
50
M22×1.5
84
43
109
12
23
32
30
37
0.6
15
38
43
0.488
PHS 25
25
31
42.86
22
60
M24×2
94
48
124
12
29.5
36
33.5
42
0.6
15
47
65
0.749
PHS 28
28
35
47.63
25
66
M27×2
103
53
136
12
32.5
41
37
46
0.6
15
59
77
0.949
PHS 30
30
37
50.8
25
70
M30×2
110
56
145
15
34
41
40
50
0.6
17
63
86
1.13
