| ↓ Products List：—— GEWZ...ES-2RS Series |
|
 |
 |
|
Bearing No. |
Boundary dimensions(mm) |
Mass |
|
d |
D |
B |
C |
d1 |
dk |
rs |
r1s |
α° |
Kg |
|
max |
min |
min |
≈ |
≈ |
|
GEWZ19ES-2RS |
19.05 |
31.75 |
28.575 |
14.275 |
23.368 |
27.5 |
0.3 |
0.6 |
5 |
0.064 |
|
GEWZ22ES-2RS |
22.225 |
36.513 |
33.325 |
16.662 |
27.178 |
32 |
0.3 |
0.6 |
5 |
0.098 |
|
GEWZ25ES-2RS |
25.4 |
41.275 |
38.1 |
19.05 |
30.988 |
36.5 |
0.3 |
0.6 |
5 |
0.142 |
|
GEWZ31ES-2RS |
31.75 |
50.8 |
47.625 |
23.8 |
38.735 |
45.5 |
0.6 |
0.6 |
5 |
0.271 |
|
GEWZ34ES-2RS |
34.925 |
55.563 |
52.375 |
26.187 |
42.418 |
49 |
0.6 |
1 |
5 |
0.373 |
|
GEWZ38ES-2RS |
38.1 |
61.913 |
57.15 |
28.575 |
46.99 |
54.7 |
0.6 |
1 |
5 |
0.494 |
|
GEWZ44ES-2RS |
44.45 |
71.438 |
66.675 |
33.325 |
54.991 |
63.9 |
0.6 |
1 |
5 |
0.762 |
|
GEWZ50ES-2RS |
50.8 |
80.963 |
76.2 |
38.1 |
62.484 |
73 |
0.6 |
1 |
5 |
1.11 |
|
GEWZ57ES-2RS |
57.15 |
90.488 |
85.725 |
42.85 |
70.104 |
82 |
0.6 |
1 |
5 |
1.57 |
|
GEWZ63ES-2RS |
63.5 |
100.013 |
95.25 |
47.625 |
77.724 |
92 |
1 |
1 |
5 |
2.15 |
|
GEWZ69ES-2RS |
69.85 |
111.125 |
104.775 |
52.375 |
85.852 |
100 |
1 |
1 |
5 |
2.9 |
|
GEWZ76ES-2RS |
76.2 |
120.65 |
114.3 |
57.15 |
93.345 |
109.5 |
1 |
1 |
5 |
3.59 |
|
GEWZ82ES-2RS |
82.55 |
130.175 |
123.825 |
61.9 |
101.219 |
119 |
1 |
1 |
5 |
4.69 |
|
GEWZ88ES-2RS |
88.9 |
139.7 |
133.35 |
66.675 |
109.22 |
128 |
1 |
1 |
5 |
5.86 |
|
GEWZ95ES-2RS |
95.25 |
149.225 |
142.875 |
71.425 |
116.586 |
137 |
1 |
1 |
5 |
7.11 |
|
GEWZ101ES-2RS |
101.6 |
158.75 |
152.4 |
76.2 |
124.587 |
146 |
1 |
1 |
5 |
8.56 |
|
GEWZ114ES-2RS |
114.3 |
177.8 |
171.45 |
85.725 |
140.335 |
164.5 |
1 |
1 |
5 |
12.24 |
|
GEWZ127ES-2RS |
127 |
196.85 |
190.5 |
95.25 |
155.705 |
183 |
1 |
1 |
5 |
16.63 |
|
GEWZ152ES-2RS |
152.4 |
222.25 |
209.55 |
104.775 |
178.308 |
207 |
1 |
1 |
5 |
20.7 | |
|
|
|
|
