| ↓ Products List：—— GEG...ES Series |
|
 |
 |
|
Bearing No. |
Boundary dimensions(mm) |
Mass |
|
d |
D |
B |
C |
dk |
rs |
r1s |
α° |
Kg |
|
min |
min |
≈ |
≈ |
|
GEG15ES |
15 |
30 |
16 |
10 |
25 |
0.3 |
0.3 |
16 |
0.049 |
|
GEG17ES |
17 |
35 |
20 |
12 |
29 |
0.3 |
0.3 |
19 |
0.083 |
|
GEG20ES |
20 |
42 |
25 |
16 |
35.5 |
0.3 |
0.6 |
17 |
0.153 |
|
GEG25ES |
25 |
47 |
28 |
18 |
40.7 |
0.6 |
0.6 |
17 |
0.203 |
|
GEG30ES |
30 |
55 |
32 |
20 |
47 |
0.6 |
1 |
17 |
0.304 |
|
GEG35ES |
35 |
62 |
35 |
22 |
53 |
0.6 |
1 |
16 |
0.408 |
|
GEG40ES |
40 |
68 |
40 |
25 |
60 |
0.6 |
1 |
17 |
0.542 |
|
GEG45ES |
45 |
75 |
43 |
28 |
66 |
0.6 |
1 |
15 |
0.713 |
|
GEG50ES |
50 |
90 |
56 |
36 |
80 |
0.6 |
1 |
17 |
1.14 |
|
GEG60ES |
60 |
105 |
63 |
40 |
92 |
1 |
1 |
17 |
2.05 |
|
GEG70ES |
70 |
120 |
70 |
45 |
105 |
1 |
1 |
16 |
3.01 |
|
GEG80ES |
80 |
130 |
75 |
50 |
115 |
1 |
1 |
14 |
3.64 |
|
GEG90ES |
90 |
150 |
85 |
55 |
130 |
1 |
1 |
15 |
5.22 |
|
GEG100ES |
100 |
160 |
85 |
55 |
140 |
1 |
1 |
14 |
6.05 |
|
GEG110ES |
110 |
180 |
100 |
70 |
160 |
1 |
1 |
12 |
9.68 |
|
GEG120ES |
120 |
210 |
115 |
70 |
180 |
1 |
1 |
16 |
14.01 |
|
GEG140ES |
140 |
230 |
130 |
80 |
200 |
1 |
1 |
16 |
19.01 |
|
GEG160ES |
160 |
260 |
135 |
80 |
225 |
1.1 |
1.1 |
16 |
20.02 |
|
GEG180ES |
180 |
290 |
155 |
100 |
250 |
1.1 |
1.1 |
14 |
32.21 |
|
GEG200ES |
200 |
320 |
165 |
100 |
275 |
1.1 |
1.1 |
15 |
45.28 |
|
GEG220ES |
220 |
340 |
175 |
100 |
300 |
1.1 |
1.1 |
16 |
51.12 |
|
GEG240ES |
240 |
370 |
190 |
110 |
325 |
1.1 |
1.1 |
15 |
65.12 |
|
GEG260ES |
260 |
400 |
205 |
120 |
350 |
1.1 |
1.1 |
15 |
82.44 |
|
GEG280ES |
280 |
430 |
210 |
120 |
375 |
1.1 |
1.1 |
15 |
97.21 | |
|
|
|
|
